Automatic Power Factor Controller

JKFG-12 12 PV Loops APFC Automatic Power Factor Controller is designed by Geyue Electric for the application of low voltage reactive power compensation in PV (photovoltaic) field: monitoring of power system line data and controlling of capacitor automatic switching
1. Model: JKFG-12
2. Overall Dimensions: 120×120mm. Mounting Dimensions: 113×113mm.
3. Output Loops: 12 loops
4. Two Working Modes: Automatic switching. Manual switching.
5. Protections: Power failure protection. Overvoltage/Undervoltage protection. Low current protection. Low power factor protection. Harmonic voltage/ Harmonic current protection (can be off).

This product is in strict accordance with the JB/T 9663-2013 and DL/T597-1996 Standards.

JKFG-24 24 Loops APFC Automatic Power Factor Controller is an advanced and intelligent automatic reactive power compensation controller painstakingly developed by Geyue Electric to closely monitor the detailed line data of the power system and accurately control the automatic switching of capacitors.
1. Model: JKFG-24
2. Overall Dimensions: 144×144mm. Mounting Dimensions: 138×138mm.
3. Output Loops: 24 loops
4. Two Working Modes: Automatic switching. Manual switching.
5. Protections: Power failure protection. Overvoltage/Undervoltage protection. Low current protection. Low power factor protection. Harmonic voltage/ Harmonic current protection (can be off).

This product is in strict accordance with the JB/T 9663-2013 and DL/T597-1996 Standards.

JKW5C-12(16) Reactive Power Auto Compensation Controller is a power factor controller which is produced by Geyue Electric for the purpose of automatically switching the power capacitor in the low voltage reactive power compensation system.

1. Model: JKW5C-12(16)
2. Mounting Dimensions: 113×113mm
3. Output Loops: 12/16 loops
4. Features: High measurement accuracy. High compensation accuracy. Friendly interface. Easy operation.
5. Two Control Modes: Power factor. Reactive power.
6. Two Working Modes: Automatic operation. Manual operation.
7. Protections: Power Loss Protection. Overvoltage protection. Undervoltage protection, and etc.

This product is strictly in accordance with the JB/T 9663-2013 and DL/T597-1996 Standards.

The JKWF series Power Compensation Controller of Geyue Electric is specifically designed for power systems below 0.4KV. It is used to precisely manage reactive power, improve power factor, and optimize power quality. It adopts a control algorithm combining fundamental reactive power and power factor, featuring 6 mixed compensation schemes, 12 intelligent coding switching, and harmonic interference suppression capabilities. It supports full digital parameter setting and permanent storage. This series of products is widely used in complex grid environments with three-phase imbalance or harmonic interference, such as industrial manufacturing, commercial buildings, and new energy power stations. It is particularly suitable for scenarios with high requirements for switching stability and compensation accuracy.

Compliance certified: JB/T 9663-2013 & DL/T 597-1996
